The Primus IQ Brake Control is a proportional electric trailer brake system designed for safe and efficient towing. It offers advanced braking technology for smooth deceleration and is compact for easy installation. This control ensures reliable performance, making it an essential component for towing safety.
1.1 Overview of the Primus IQ Brake Control
The Primus IQ Brake Control is a proportional electric trailer brake system offering advanced braking technology. It provides smooth, responsive braking in both forward and reverse directions. Designed for ease of use, it features Tekonsha’s Point and Go set-up system for quick installation. The control ensures precise braking proportional to vehicle deceleration, enhancing towing safety and control, with a manual override option for added convenience.
1.2 Importance of Proper Brake Control for Trailer Safety
Proper brake control ensures trailer brakes synchronize with vehicle brakes, preventing skidding or jackknifing; Improper control can lead to dangerous situations, emphasizing the need for precise synchronization. The Primus IQ Brake Control enhances safety by maintaining proportional braking, crucial for secure towing and minimizing risks during sudden stops or uneven terrain, ensuring both vehicle and trailer remain under control.
Key Features of the Primus IQ Brake Control
The Primus IQ Brake Control features proportional braking, reverse proportional capability, and Tekonsha’s Point and Go set-up system for precise and efficient trailer braking control.
2.1 Proportional Braking Technology
The Primus IQ employs proportional braking technology, which adjusts trailer brake pressure based on the vehicle’s deceleration. This ensures smooth, synchronized stopping, enhancing control and safety while towing. The system automatically applies the correct voltage, preventing abrupt stops and maintaining stability, especially in hilly terrain or emergency braking situations.
2.2 Reverse Proportional Braking Capability
The Primus IQ offers reverse proportional braking, applying trailer brakes in proportion to deceleration even when in reverse. This feature enhances control and stability while maneuvering in tight spaces, ensuring smooth and safe trailer movement during backing operations.
2;3 Tekonsha’s Point and Go Set-Up System
Tekonsha’s Point and Go Set-Up System simplifies installation and calibration of the Primus IQ Brake Control; This intuitive system allows users to quickly configure settings with minimal effort, ensuring a seamless setup process for optimal braking performance. Its user-friendly design makes it accessible for both novice and experienced users alike.
Installation Requirements and Precautions
Ensure vehicle and trailer compatibility, proper mounting orientation, and use of OEM-specific wiring harnesses. Avoid installing near RF-generating devices like cell phones or radios within 12 inches.
3.1 Vehicle and Trailer Compatibility
Ensure your vehicle and trailer are compatible with the Primus IQ Brake Control. Verify the trailer’s braking system type and total weight. Check if your vehicle has a factory tow package or 7-way connector. Compatibility is crucial for safe and effective braking performance. Always refer to the manufacturer’s specifications for proper pairing and installation.
3.2 Mounting Orientation and Location Guidelines
Mount the Primus IQ Brake Control between 0° and 70° nose-up to ensure proper function. Avoid areas near RF devices like cell phones or two-way radios within 12 inches. Secure the unit firmly to prevent movement during travel. Placement should allow easy access to controls and visibility of the display for safe and effective braking operation at all times.
3.3 Use of OEM Specific Wiring Harness
For seamless installation, use an OEM-specific wiring harness designed for your vehicle. This ensures compatibility with the Primus IQ Brake Control and your vehicle’s tow package. If your vehicle has a factory 7-way connector, purchase a Tekonsha OEM harness with connectors for both the Brake Control and your vehicle. Follow the manufacturer’s instructions for proper connection to avoid electrical issues and ensure safe operation.
Step-by-Step Installation Guide
Mount the Brake Control unit, wire it to your vehicle’s electrical system, and test the brakes to ensure proper functionality. Follow the manual for precise steps.
4.1 Preparing the Vehicle and Trailer
Ensure your vehicle and trailer are compatible with the Primus IQ Brake Control. Use an OEM-specific wiring harness for proper connectivity. Verify the tow package and 7-way connector are installed; Mount the control unit at an angle between 0° and 70° nose up. Avoid placing RF devices like cell phones near the control to prevent interference. Follow all safety guidelines before proceeding.
4.2 Wiring the Brake Control
Connect the wiring harness to the Primus IQ Brake Control, ensuring all terminals match the vehicle’s wiring system. Use an OEM-specific harness for compatibility. Secure the wiring neatly, avoiding heat sources. Plug the pigtail into the control and connect to the vehicle’s 7-way connector. Test the wiring to ensure proper functionality before finalizing the installation. Follow the manual for precise wiring instructions.
4.3 Mounting the Brake Control Unit
Mount the Primus IQ Brake Control unit securely in a visible and accessible location. Ensure the unit is installed at an angle between 0 and 70 degrees nose-up for proper functionality. Use the provided dash mounting clip to secure the control firmly. Tighten screws gently to avoid damage. Follow the manual for precise mounting instructions to guarantee optimal performance and safety.
4.4 Testing the Brake Control System
After installation, test the Primus IQ Brake Control to ensure proper function. With the trailer connected, check the display for power and connection status. Engage the manual override to verify trailer brakes activate. Test proportional braking by accelerating and decelerating, ensuring smooth trailer braking. Also, test reverse braking to confirm proportional braking in reverse gear. Always test in a controlled environment for safety.
Initial Setup and Configuration
The Primus IQ Brake Control requires calibration to synchronize with your trailer’s brakes. Adjust the power setting to match your vehicle and trailer weight for optimal braking performance. Follow the calibration process to ensure smooth, proportional braking in both forward and reverse directions, enhancing overall towing safety and control.
5.1 Understanding the Brake Control Display
The Primus IQ Brake Control features a two-digit display showing system status, power levels, and error codes. It indicates when the trailer is connected and if there are issues. Proper mounting ensures accurate readings. The display helps monitor braking performance and troubleshoot problems efficiently, providing clear feedback for safe towing operations.
5.2 Adjusting the Power Setting
Adjust the power setting on the Primus IQ Brake Control by turning the manual knob until the display shows the desired level. This setting determines the braking force applied to the trailer. Proper adjustment ensures smooth, proportional braking without over- or under-applying the brakes, enhancing towing safety and control for various trailer loads and driving conditions.
5.3 Calibration Process for Proper Braking
Calibrate the Primus IQ Brake Control by adjusting the power setting and testing the brakes. The display will show codes during calibration. Ensure the trailer brakes engage smoothly and proportionally. Proper calibration is crucial for safe and effective braking performance. Refer to the manual for detailed steps and troubleshooting tips to achieve optimal braking functionality.
Operating the Primus IQ Brake Control
The Primus IQ Brake Control operates smoothly, offering proportional braking, reverse functionality, and manual override. Ensure proper setup and adjustment for consistent, safe braking performance.
6.1 Using the Manual Override Feature
The manual override feature allows you to apply the trailer brakes independently of the vehicle’s brakes. Simply slide the manual knob to activate it, providing additional control when needed. This feature is particularly useful in emergencies or for extra braking power. Ensure the vehicle is stationary before using the override for optimal effectiveness and safety.
6.2 Understanding Proportional Braking in Motion
The Primus IQ Brake Control employs proportional braking technology, which applies brake voltage to the trailer in proportion to the vehicle’s deceleration. This ensures smooth, synchronized braking between the vehicle and trailer, reducing the risk of jerky stops. The system automatically adjusts based on the vehicle’s speed and deceleration, providing consistent and reliable braking performance while in motion.
6.3 Braking in Reverse Gear
The Primus IQ Brake Control features reverse proportional braking, ensuring smooth and controlled trailer braking while in reverse. The system applies the appropriate brake voltage based on deceleration, maintaining stability and preventing trailer sway. This functionality enhances safety and maneuverability when backing up, making it easier to navigate tight spaces with confidence.
Troubleshooting Common Issues
Identify and resolve common issues like connection problems or display errors. Check wiring, ensure proper setup, and refer to the manual for detailed solutions and support contact information.
7.1 Identifying and Solving Connection Problems
Check all wiring connections for tightness and damage. Ensure the brake control is properly connected to the vehicle’s electrical system using an OEM-specific harness. Verify the trailer connector is clean and free of corrosion. Consult the manual for wiring diagrams and troubleshooting steps. If issues persist, contact Tekonsha customer support for assistance.
7.2 Addressing Brake Control Display Errors
Check the display for error codes or unusual readings. Ensure the brake control has power and all connections are secure. If issues persist, recalibrate the system or reset the control. Refer to the manual for specific error code meanings and solutions. Contact Tekonsha support if problems remain unresolved after troubleshooting steps.
7.3 Resolving Proportional Braking Malfunctions
Check connections and wiring for integrity. Ensure proper sensor alignment and calibration. If braking feels inconsistent, inspect the trailer brakes for wear or misadjustment. Verify power levels and adjust settings as needed. Consult the manual for recalibration steps. If issues persist, contact Tekonsha support for further assistance or potential component replacement.
Maintenance and Care Tips
Regularly inspect wiring and connections for damage or corrosion. Clean the control unit with a soft cloth to prevent dust buildup. Ensure all components are securely mounted and functioning properly. Replace worn-out parts promptly to maintain optimal braking performance and safety.
8.1 Cleaning the Brake Control Unit
Use a soft, dry cloth to gently wipe the Primus IQ Brake Control unit, removing dust or debris. Avoid harsh chemicals or abrasive materials that could damage the surface. Regular cleaning ensures optimal functionality and prevents dust buildup that might interfere with the control’s performance. Refer to the manual for detailed cleaning instructions to maintain your unit effectively.
8.2 Regular Inspection of Wiring and Connections
Inspect wiring and connections regularly for damage, corrosion, or wear. Ensure all connections are secure and properly tightened. Consult the manual for correct wiring diagrams and procedures. Damaged wires or loose connections can lead to system malfunctions. Address any issues promptly to maintain safe and reliable braking performance. If unsure, seek professional assistance for thorough inspection and repairs.
8.3 Updating or Replacing Components
Regularly update or replace components to ensure optimal performance. Replace worn-out parts like wiring harnesses or sensors. Use genuine Tekonsha parts for compatibility. Follow the manual’s guidelines for replacements. Updating software, if applicable, ensures the latest features and bug fixes. Always test the system after any modifications to confirm proper functionality and safety. This maintains reliability and extends the product’s lifespan.
Warranty and Technical Support
The Primus IQ Brake Control is backed by a comprehensive warranty. For technical support, contact Tekonsha at 1-888-785-5832 or visit their website for detailed resources.
9.1 Understanding the Warranty Coverage
The Primus IQ Brake Control is covered by a limited warranty that protects against defects in materials and workmanship. The warranty period varies depending on the product and usage, ensuring coverage for parts and labor under normal operating conditions. For specific details, refer to the warranty section in the manual or contact Tekonsha support;
9.2 Contacting Tekonsha Customer Support
For technical assistance or warranty inquiries, contact Tekonsha customer support at 1-888-785-5832. Additional resources, including manuals and FAQs, are available on their official website at www.tekonsha.com. This ensures quick access to help and detailed information for troubleshooting or understanding your Primus IQ Brake Control.
9.4 Accessing Online Resources and Manuals
Visit the official Tekonsha website at www.tekonsha.com to access detailed manuals, installation guides, and troubleshooting resources for the Primus IQ Brake Control. The website offers downloadable PDF manuals, ensuring easy access to comprehensive instructions and technical specifications for proper setup and maintenance of your brake control system.
The Primus IQ Brake Control is a top choice for trailer braking efficiency and safety, offering proportional braking and ease of use. Always follow manual guidelines for optimal performance and safe towing practices.
10.1 Summary of Key Features and Benefits
The Primus IQ Brake Control offers proportional braking for smooth deceleration, reverse proportional braking capability, and the Tekonsha Point and Go set-up system. Its compact design ensures easy installation and use, while the manual override feature provides added control. The system is compatible with OEM wiring harnesses, enhancing reliability and safety for towing applications. Regular maintenance ensures optimal performance and longevity.
10.2 Final Tips for Safe and Effective Use
Always follow the manual for installation and operation. Regularly inspect wiring and connections for damage. Use the manual override during emergencies. Ensure proper calibration for different trailer setups. Avoid mounting near RF devices to prevent interference. Store the manual for future reference. These practices maximize safety and ensure optimal performance of the Primus IQ Brake Control.
